ASTM A182 F5 Drip rings, inserts and bleed rings are essential components used in piping systems for various industrial applications. Made from high-quality materials, these rings offer excellent hardness, corrosion resistance, and durability, making them an ideal choice for use in harsh and challenging environments.
|
Grade
|
Heat Treat Type
|
Austenitizing/Solutioning Temperature, Minimum or Range, ℉［℃］A
|
Cooling Media
|
Quenching Cool Below ℉［℃］
|
Tempering Temperature, Minimum or Range, ℉［℃］
|
|
F5
|
anneal
|
1750［955］
|
Furnace cool
|
B
|
1250［675］
|
|
|
Normalize and temper
|
Air cool
|
B
|
The drip rings made from ASTM A182 F5 are highly effective in preventing leaks and protecting the environment from any hazardous substances that may escape from the piping system.
ASTM A182 F5 Inserts offer excellent strength and reliability, ensuring pipe connections and prevent damage.
A182 F5 Bleed rings offer excellent corrosion resistance, facilitate maintenance and testing by providing a controlled access point.
|
Grade
|
UNS Designation
|
C
|
Mn
|
P
|
S
|
Si
|
Ni
|
Cr
|
Mo
|
Co
|
Ti
|
Other Elements
|
|
F5
|
K41545
|
0.15
|
0.30-0.60
|
0.030
|
0.030
|
0.50
|
0.50
|
4.0-6.0
|
0.44-0.65
|
...
|
...
|
...
|
|
Grade Symbol
|
Tensile Strength, min, ksi［Mpa］
|
Yield Strength, min, ksi［Mpa］
|
Elongation in 2 in.［50mm］or 4D, min, %
|
Reduction of Area, min, %
|
Brinell Hardness Number, HBW, unless otherwise indicated
|
|
F5
|
70［485］
|
40［275］
|
20
|
35
|
143-217
|
ASTM A182 F5 Drip rings, inserts, and bleed rings play a crucial role in piping systems, providing essential services such as leak prevention, connection reinforcement, and access for maintenance and testing. Their high quality and durability make them an ideal choice for use in a wide range of industrial applications.
