  • Alloy 20 UNS N08020 round bar
  • Alloy 20 UNS N08020 round bar

316 UNS S31600 round bar

  • product name:Bar
  • Material:316
  • Manufacture Technique:Hot Rolling, Cold-drawing
  • Diameter:5~500mm

ASTM/ASME SB 473 Alloy20/UNS N08020 nickel-iron-chromium austenitic alloy bar



Alloy 20, also known as Carpenter 20, is a nickel-iron-chromium austenitic alloy that was developed for maximum resistance to acid attack, specifically sulfuric acid. This superalloy has excellent resistance to general corrosion, pitting, and crevice corrosion in chemicals containing chlorides and sulfuric, phosphoric, and nitric acids. It also contains niobium for stabilization against sensitization and resultant intergranular corrosion. Carpenter 20 combines excellent corrosion resistance with elevated mechanical properties and relatively easy fabrication. Although originally designed for use in sulfuric acid related industries, Alloy 20 is now a popular choice for a wide variety of industries including the chemical, food, pharmaceutical, and plastics industries. In addition, this superalloy is used in heat exchangers, mixing tanks, metal cleaning and pickling equipment, and piping.



There has long been a debate on whether Carpenter 20 is a stainless steel or a nickel alloy because the nickel content is right on the border of defining it as one way or the other. So, depending on who you talk to this alloy may be referred to as alloy 20 Stainless Steel or as a nickel alloy. Either way it is still great for corrosion resistance.



What are the characteristics of Alloy 20?

  • Excellent general corrosion resistance to sulfuric acid
  • Excellent resistance to chloride stress corrosion cracking
  • Excellent mechanical properties and fabricability
  • Minimal carbide precipitation during welding
  • Excels in resisting corrosion to hot sulfuric acids

Chemical Composition, %

Ni Fe Cr Cu Mo Nb C Mn P S Si
32.00-38.00 Balance 19.0-21.0 3.0-4.0 2.0-3.0 8xC-1.0 max .07max 2.0 max .045 max .035 max 1.0 max



In what applications is Alloy 20 used?

  • Synthetic rubber manufacturing equipment
  • Processing of pharmaceuticals, plastics and organic and heavy chemicals
  • Tanks, piping, heat exchangers, pumps, valves, and other process equipment
  • Acid cleaning and pickling equipment
  • Chemical process piping, reactor vessels
  • Bubble caps
  • Petrochemical process equipment
  • Food and dye production

ASTM Specifications

Pipe Smls Pipe Welded Tube Smls
Tube Welded Sheet/Plate Bar Forging Fitting
B729 B464 B729 B468 B463 B473 B462 B366

Mechanical Properties

Annealed Material

Form Tensile Min. Yield Min. (.2% offset) Elongation Min. Reduction of Area Min.
Bar (hot or cold finished) 80 ksi 35 ksi 30% 50%
Sheet/Plate 80 ksi 35 ksi 30% -



Mechanical & Physical Properties :

Element Alloy 20
Density 8.1 g/cm3
Melting Point 1443 °C (2430 °F)
Tensile Strength Psi -80,000, MPa -551
Yield Strength (0.2%Offset) Psi - 35,000, MPa - 241
Elongation 30 %
