  • incoloy 825 plate sheet

incoloy 825 plate sheet

  • Material Grade:incoloy 825
  • Width:0~2500mm or as per your requirements
  • Length:0~12m or as per your requirements
  • Thickness:0.3~1200mm or as per your requirements

PRODUCT DESCRIPTION

ASTM B424 Alloy Incoloy 825 plate sheet strip with USA SMC ATI GERMANY VDM origin





1. Incoloy 825 Sheet / Plate / Coil



Incoloy UNS N08825 Plates, Incoloy Alloy 825 Coils, 825 Incoloy Hot Rolled Plates, Incoloy 825 Plates, Alloy 825 Sheets, JIS NCF 825 Plate, ASME SB 424 Incoloy 825 Plate Supplier in China.

Incoloy Alloy 825 Coils Suppliers, 825 Alloy Plate, Incoloy 825 Cold Rolled Plates Exporter, ASTM B 424 Incoloy 825 Shim Sheets, Incoloy 825 Sheets, Incoloy Werkstoff No 2.4858 Sheets Manufacturer in China.



2. What Is Incoloy 825 Sheet / Plate / Coil?



We are one of the leading Supplier, Manufacturers of high and best quality Incoloy 825 Sheet / Plate / Coil. Best quality of Incoloy 825 Sheets, Plates and Coils at lowest price, Incoloy 825 Coils, Sheets, Plates. Incoloy 800H Cold Rolled Sheet, Incoloy UNS N08825 Plates Wholesaler, Incoloy 825 Coils, Incoloy 825 Profile Manufacturer in China.

Aries Alloys is a known Stockist of Alloy 825 Plates, Sheets, which is available in dissimilar shapes and sizes. We make, supply a promising products line of Incoloy Alloy 825 Coils Suppliers in Mumbai,India. Plates and Sheet Range is 4 mm to 90 mm thick in upto 2200 mm width & upto 5500 length. check Price list of Incoloy 825 Plate, Sheet & Coil in Turkey, Australia, New Zealand, Iran, Germany, UK, Canada, Russia, Sri Lanka, Vietnam and China.

Incoloy 825 Sheet / Plate / Coil, 825 Incoloy Plate Stockholder, 825 Incoloy Polished Cold Drawn Plates, Distributors Of Incoloy GOST ЭП703 Strips, ASME SB424 Incoloy 825 Coils Manufacturer.



3. Specification of Incoloy 825 Sheet / Plate / Coil



Specifications ASTM / ASME SB 424
Size 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Thickness 0.1mm to 12 mm Thk
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.



Equivalent Grades for 825 Incoloy Sheets, Plates & Coils

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 825 2.4858 N08825 NCF 825 NA 16 ЭП703 NFE30C20DUM NiCr21Mo XH38BT



Incoloy 825 Plate, Sheet & Coil Chemical Composition

Grade C Mn Si S Cu Fe Ni Cr Al Ti
825 0.05 max 1.00 max 0.5 max 0.03 max 1.50 – 3.00 22.00 min 38.00 – 46.00 19.50 – 23.50 0.02 max 0.06 – 1.20



Alloy 825 Sheet, Plate & Coil Mechanical Properties

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
825 8.14 g/cm3 1400 °C (2550 °F) Psi – 80,000 , MPa – 550 Psi – 32,000 , MPa – 220 30 %


3. Incoloy 825 Plates / Sheets / Coils Sizes



STOCKED SIZES
SIZE ALLOY 825 PLATE/ SHEET SIZE
.125" Incoloy 825 Plate, Incoloy 825 Perforated Plate, Incoloy 825 Sheet 3.18mm
.134" Incoloy 825 Coil, Incoloy 825 Plate, Incoloy 825 Strips 3.40mm
.156" Incoloy 825 Plate, Incoloy 825 Perforated Plate, Incoloy 825 Sheet 3.96mm
.187" Incoloy 825 Plate, Incoloy 825 Sheet, Incoloy 825 Rolling Plate 4.75mm
.250" Incoloy 825 Plate, Incoloy 825 Rolling Sheets, Incoloy 825 Sheet 6.35mm
.312" Incoloy 825 Plate, Incoloy 825 Perforated Plate, Incoloy 825 Sheet 7.92mm
.375" Incoloy 825 Plate, Incoloy 825 Rolling Plate, Incoloy 825 Sheet 9.53mm
.500" Incoloy 825 Plate, Incoloy 825 Sheet, Incoloy 825 Clad Plate 12.7mm
.625" Incoloy 825 Plate, Incoloy 825 Flat Shim, Incoloy 825 Sheet 15.9mm
.750" Incoloy 825 Plate, Incoloy 825 Sheet, Incoloy 825 Strips 19.1mm
.875" Incoloy 825 Plate, Incoloy 825 Rolling Sheets, Incoloy 825 Sheet 22.2mm
1" Incoloy 825 Plate, Incoloy 825 Flat Shim, Incoloy 825 Sheet 25.4mm
1.125" Incoloy 825 Plate, Incoloy 825 Sheet, Incoloy 825 Clad Plate 28.6mm
1.250" Incoloy 825 Plate, Incoloy 825 Sheet, Incoloy 825 Strips 31.8mm
1.500" Incoloy 825 Plate, Incoloy 825 Rolling Plate, Incoloy 825 Sheet 38.1mm
1.750" Incoloy 825 Plate, Incoloy 825 Sheet, Incoloy 825 Clad Plate 44.5mm
2" Incoloy 825 Plate, Incoloy 825 Clad Plate, Incoloy 825 Sheet 50.8mm
2.500" Incoloy 825 Plate, Incoloy 825 Flat Shim, Incoloy 825 Sheet 63.5mm
3" Incoloy 825 Plate, Incoloy 825 Rolling Sheets, Incoloy 825 Sheet 76.2mm



4. Incoloy 825 Plates / Sheets / Coils Price List



Size in mm PACK QTY PRICE
Price of Incoloy 825 plate 0.4 thick x 250 x 250 1 $92.73
Price of Incoloy 825 plate 0.4 thick x 250 x 250 2 $140.50
Price of Incoloy 825 Sheet 0.4 thick x 250 x 250 3 $184.06
Price of Incoloy 825 plate 0.4 thick x 250 x 250 4 $221.99
Price of Incoloy 825 plate 0.4 thick x 500 x 500 2 $340.01
Price of Incoloy 825 Sheet 0.4 thick x 500 x 500 3 $455.22
Price of Incoloy 825 plate 0.5 thick x 250 x 250 1 $101.16
Price of Incoloy 825 plate 0.5 thick x 250 x 250 2 $157.36
Price of Incoloy 825 Sheet 0.5 thick x 250 x 250 3 $207.94
Price of Incoloy 825 plate 0.5 thick x 500 x 500 2 $387.78
Price of Incoloy 825 plate 0.5 thick x 500 x 500 3 $524.07
Price of Incoloy 825 Sheet 0.5 thick x 1000 x 1000 1 $632.25
Price of Incoloy 825 plate 0.7 thick x 250 x 250 1 $130.67
Price of Incoloy 825 Sheet 0.7 thick x 250 x 250 2 $206.54
Price of Incoloy 825 plate 0.7 thick x 250 x 250 3 $276.79
Price of Incoloy 825 plate 0.7 thick x 500 x 500 2 $529.69
Price of Incoloy 825 Sheet 0.7 thick x 500 x 500 3 $720.77
Price of Incoloy 825 plate 0.8 thick x 250 x 250 1 $134.88
Price of Incoloy 825 Sheet 0.8 thick x 250 x 250 15 $1,091.69
Price of Incoloy 825 plate 0.8 thick x 500 x 500 1 $317.53
Price of Incoloy 825 Sheet 0.8 thick x 500 x 500 3 $821.93
Price of Incoloy 825 plate 0.8 thick x 500 x 500 5 $1,243.43
Price of Incoloy 825 Sheet 0.8 thick x 1000 x 1000 1 $923.09
Price of Incoloy 825 plate 0.8 thick x 1000 x 2000 1 $1,809.64
Price of Incoloy 825 plate 1.0 thick x 250 x 250 1 $148.93
Price of Incoloy 825 Sheet 1.0 thick x 250 x 250 10 $958.21
Price of Incoloy 825 plate 1.0 thick x 250 x 250 15 $1,246.24
Price of Incoloy 825 Sheet 1.0 thick x 500 x 500 5 $1,419.05
Price of Incoloy 825 plate 1.0 thick x 500 x 500 7 $1,812.45
Price of Incoloy 825 Sheet 1.2 thick x 250 x 250 3 $376.54
Price of Incoloy 825 plate 1.2 thick x 250 x 250 5 $571.84
Price of Incoloy 825 Sheet 1.2 thick x 250 x 250 10 $1,045.32
Price of Incoloy 825 plate 1.2 thick x 250 x 250 15 $1,362.85
Price of Incoloy 825 plate 1.2 thick x 500 x 500 5 $1,551.12
Price of Incoloy 825 Sheet 1.2 thick x 1000 x 1000 1 $1,146.48
Price of Incoloy 825 Sheet 1.6 thick x 250 x 250 10 $1,244.83
Price of Incoloy 825 plate 1.6 thick x 250 x 250 15 $1,624.18
Price of Incoloy 825 plate 1.6 thick x 500 x 500 3 $1,124.00
Price of Incoloy 825 Sheet 1.6 thick x 500 x 500 5 $1,700.05
Price of Incoloy 825 plate 2.0 thick x 100 x 100 20 $491.75
Price of Incoloy 825 Sheet 2.0 thick x 100 x 100 30 $678.62
Price of Incoloy 825 plate 2.0 thick x 250 x 250 1 $151.74
Price of Incoloy 825 Sheet 2.0 thick x 250 x 250 5 $578.86
Price of Incoloy 825 plate 2.0 thick x 500 x 500 3 $1,242.02
Price of Incoloy 825 Sheet 3.0 thick x 100 x 100 1 $70.25
Price of Incoloy 825 plate 3.0 thick x 100 x 100 10 $351.25
Price of Incoloy 825 Sheet 3.0 thick x 250 x 250 10 $1,466.82
Price of Incoloy 825 plate 3.0 thick x 250 x 250 15 $2,018.99
Price of Incoloy 825 plate 3.0 thick x 250 x 250 5 $671.59
Price of Incoloy 825 Sheet 3.0 thick x 250 x 250 10 $1,222.35



5. Incoloy 825 Plate, Sheet, Coil Dimensions



Incoloy 825 Plate Metric Dimensions
Surface finish Thickness (mm) Width (mm)
2B – Cold rolled, heat treated, pickled, skin passed 0.25–8.0 max. 2032
2D – Cold rolled, heat treated, pickled 0.4–6.35 max. 1524
2E – Cold rolled, heat treated, mechanically descaled 0.4–8.0 max. 2032
2R – Cold rolled, bright annealed 0.25–3.5 max. 1524
2H – Work hardened 0.4–6.35 max. 1524
Polished, brushed 0.5–4.0 max. 1524



6. Incoloy 825 Sheet, Plate & Coil Stock For Sale



Incoloy 825 Sheet / Plate / Coil, 825 alloy coil stockholder, incoloy alloy 825 hot rolled plates dealers, incoloy 825 sheets exporter in China, incoloy 825 plates Exporter in China, incoloy 825 chequered plate, incoloy UNS N08825 coils, 825 incoloy alloy shim sheets, incoloy 825 sheets price, incoloy 825 plates price China, incoloy 825 sheet, alloy 825 sheets specification, incoloy 825 cold rolled sheet distributors, asme SB168 alloy 825 sheets suppliers, incoloy DIN 2.4858 sheets, 825 incoloy plates, coils, incoloy alloy 825 plates.
