Cold Hot rolled Alloy Hastelloy C-276 ASTM B575 N10276 Plate Sheet Strip Coil
HT PIPE FITTINGS CO.LTD is one of the renowned manufacturer and suppliers of Hastelloy C276 Sheets , which can be formed using various cold and hot working processes. Although it tends to work harden it can be cold formed using the more aggressive methods such as deep - drawing, press forming or punching.
Hastelloy C276 Plates offered by HT PIPE FITTINGS CO.LTD is the alloy for outstanding performance in a range of aggressive environments. It is resistant to strong oxidizing chlorides, reducing acids, hot seawater and brine solutions. These Alloy C276 Sheets is used in a variety of environments from moderately oxidizing to strong reducing conditions. Hot forming should be performed within a temperature range between 1600 Degree F and 2250 Degree F (870 Degree C – 1230 Degree C) with heavier sections heated to a minimum of 2000 Degree F before forming.
These Alloy C276 Plates offered by HT PIPE FITTINGS CO.LTD is a versatile austenitic nickel – chromium – molybdenum – tungsten alloy. Parts which have been hot - formed should be solution heat - treated prior to final fabrication or installation, if possible. A prime advantage of these Hastelloy C276 Coils is that it generally does not require solution heat treatment after welding.
The high chromium content provides good resistance to oxidizing media while the molybdenum and tungsten content give good resistance to reducing media. HT PIPE FITTINGS CO.LTD also offer these Alloy C276 Coils in different sizes, shapes and designs as per clients’ specifications at reasonable price.
UNS N10276 Hastelloy Alloy Shim Sheet, Alloy C276 Plates, C276 Hastelloy Coils & C276 Alloy Foils Manufacturer in China
1. Hastelloy C276 Sheets, Plates & Coils Specification
| Standards |
ASTM B575, B333 / ASME SB575, SB333 |
| Sheet & Plate in Form of |
Coils, Foils, Flats, Strip, Blank (Circle), Ring (Flange) & Perforated Sheet Etc. |
2. C276 Hastelloy Alloy Sheets, Alloy C276 Plates, Hastelloy C276 Coils Specification:
| Grade |
Hastelloy Alloy C276, UNS N10276, Werkstoff Nr. 2.4819 |
| Type |
Sheet, Plates, Coils, Flat, Strips, Profile, Blank ,Circle, Ring etc. |
| Thickness |
0.3mm To 200mm |
| Width |
200mm to 3000mm |
| Length |
500mm to 12000mm |
| Finish |
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA, NO.1, NO.4, NO.8, Satin (Met with Plastic Coated), 8K, mirror, etc |
| Form |
Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Hardness |
Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Hastelloy Alloy C276 Perforated Sheet, Alloy C276 Chequered Plate, UNS N10276 Sheet, C276 Hastelloy Coils, C276 Alloy Foils & Hastelloy
C276 Coils Supplier & Exporter in China.
3. Equivalent Grades of Hastelloy C276 Plates, Sheets & Coils:
| STANDARD |
UNS |
EN |
WERKSTOFF NR. |
JIS |
OR |
GOST |
| Hastelloy C276 |
N10276 |
NiMo16Cr15W |
2.4819 |
NW 0276 |
ЭП760 |
ХН65МВУ |
4. Hastelloy C276 Plates, Sheets & Coils Chemical Composition:
| Grade |
C |
Mn |
Si |
S |
Co |
Ni |
Cr |
Fe |
Mo |
P |
| C276 |
0.010 max |
1.00 max |
0.08 max |
0.03 max |
2.50 max |
50.99 min* |
14.50 – 16.50 |
4.00 – 7.00 |
15.00 – 17.00 |
0.04 max |
5. C276 Hastelloy Plates, Sheets & Coils Mechanical Properties:
| Element |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| Hastelloy C276 |
8.89 g/cm3 |
1370 °C (2500 °F) |
Psi – 1,15,000 , MPa – 790 |
Psi – 52,000 , MPa – 355 |
40 % |
6. Available Types of C276 Hastelloy Coils, Hastelloy Alloy C276 Sheets & Hastelloy C276 Plates
Hastelloy Alloy C276 Plates
Hastelloy Alloy C276 Rolls
C276 Alloy Ring
Alloy UNS N10276 Blank
C276 Hastelloy Alloy Coils
UNS N10276 Coils
C276 Hastelloy Hot Rolled Plates
C276 Hastelloy Alloy Sheets
Hastelloy C276 Chequered Plate
Hastelloy Alloy C276 Circles
Alloy C276 Flat
Hastelloy Alloy C276 Profile
UNS N10276 Plates
C276 Alloy Cold Rolled Plates
Alloy C276 Shim Sheet
Hastelloy C276 Perforated Sheet
Alloy C276 Coils
Hastelloy C276 Strips
Alloy C276 Foils
UNS N10276 Sheets
C276 Hastelloy Polished Plates
7. We Export To
Durban, Ethiopa, Harare, Giza, Democratic Republic of the Congo, Addis Ababa, Port Elizabeth, South Africa, Kaduna, New York, Chine, Lagos, Tripoli, Yemen, Azerbaijan, UAE, Ouagadougou, Singapore, Canada, Dar es Salaam, Israel, Algiers, Dakar, Freetown, Houston, Venezuela, Colombo, Lebanon, Peru, Mozambique, Egypt, Brazil, Angola, Germany, Lubumbashi, Cyprus, Sudan, Abidjan, Mogadishu, Maiduguri, Port Harcourt, Fez, Douala, Malaysia, Kolwezi, Mexico, Khartoum, Antananarivo, Sri Lanka, Thailand (Bangkok), Jordan, Iraq, Conakry, Indonesia, Kampala, Alexandria, Colombia, Australia, Russia, Zaria, Uganda, Accra, Kazakhstan, Johannesburg, Luanda, Cairo, Subra al-Haymah, Pretoria, Bulawayo, Cameroon, United States, Soweto, Kuwait, Ghana, Maputo, Omdurman, New Zealand, Tunisia, Oman, Hong Kong, Iran, Kinshasa, Africa, Kano, Morocco, Rabat, Italy, Argentina, Brazzaville, Trinidad and Tobago, Yaoundé, Casablanca, Mbuji-Mayi, Saudi Arabia, Abu Dhabi, Dubai, UK, Qatar, London, Nairobi, Algeria, Cape Town, Nigeria, Bamako, Ibadan, Benin, Bahrain, Turkey, Vietnam.
