ASTM A240 S30409, also known as 304H stainless steel, is a high-carbon variant of the popular 304 stainless steel grade.
ASTM A240 UNS S30409 stainless steel plate Material Composition:
Iron (Fe): Bal.
Chromium (Cr): 18.0 - 20.0%
Nickel (Ni): 8.0 - 10.5%
Manganese (Mn): ≤2.0%
Silicon (Si): ≤0.75%
Carbon (C): 0.04 - 0.10%
Phosphorus (P): ≤0.045%
Sulfur (S): ≤0.030%
Nitrogen (N): ≤0.10%
ASTM A240 S30409 stainless steel plate mechanical properties:
Tensile Strength: ≥515 MPa (75,000 psi)
Yield Strength: ≥205 MPa (30,000 psi)
Elongation: ≥40%
Hardness: ≤201 HBW
UNS S30409 304H stainless steel plate sheet strip Specification
| Type |
Plate, sheet, coil, strip |
| Standard |
ASTM,AISI, AMS,MLS,EN,JIS,DIN,GOST |
| Thickness |
1.2-100mm |
| Width |
1000-1500mm |
| Length |
1000-6000mm |
| Surface |
2B, No.3, No.4, HL, BA, 8K |
| Manufacturing process |
Hot rolled, cold rolled |
| Duplex Steel |
SAF 2205/UNS S31803, SAF 2507/UNS S32750, S32760, S31200, S39277, S32520, S32205, S32250, N08904/1.4539, 254SMO/S31254/1.4574, 17-4PH/S17400/1.4548, 724L, 316Lmod/1.4435, 725LN/310MoLN |
| Packing |
Bubble bag and plywood pallet or according to the customers' requirements. The inner size of container is below: 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM |
| Delivery time |
10-100 days depending on quantity |
| Payment terms |
T/T |
| Shipment |
FOB Tianjin/Shanghai, CIF, CFR, etc |
| Application |
Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc |
| Remarks |
Other materials and drawings are available. |
| Welcome to contact us ;Zhengzhou Huitong Pipe Fittings Co.,Ltd (32 years manufacturing experience) |
HT PIPE is supplier and manufactuter of Stainless steel Plates. If you have inquiry, pls contact us!
