  • Inconel plate supplier
  • Inconel 625 plate
  • Inconel 625  steel sheet
  • Inconel 718 sheet

Inconel steel plate sheet Coil

  • Material: Inconel 600, 601, 625, 718
  • Width: 0~2500mm or as per your requirements
  • Length: 0~12m or as per your requirements
  • Thickness: 0.3~1200mm or as per your requirements

PRODUCT DESCRIPTION

Inconel Alloy plates are a nickel-chrome-based super alloys characterized by high corrosion resistance, oxidation resistance, strength at high temperatures, and creep resistance. Inconel is able to withstand elevated temperatures and extremely corrosive environments due to two factors. HT PIPE is a manufacturer, exporter, and supplier of Inconel 600 plates, Inconel 601 plates, Inconel 625 plates sheets. Inconel Alloy Sheets & Plates Stockist, Inconel 600 Plates Exporter, Nickel Alloy Sheets & Plates, Inconel 625 Hot Rolled Sheets, Inconel 625 Sheets, Inconel 625 Plates, Inconel Coils, Inconel 718 Plates, Inconel Cold Rolled Plates, ASTM B168 Inconel 600 Sheets, Plates and Coils Supplier in China.

Specification For Inconel 600, 601, 625, 718 steel plates/sheets/coils:
Thickness: 0.1mm to 12 mm Thk
Sheet/Plate Size: 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Coil Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc.
Coil Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc.

Inconel 600, 601, 625, 718 steel plates/sheets/coils Chemical Composition:
Grade C≤ Mn≤ Si≤ S≤ Cu≤ Fe Ni Cr
Inconel 600 0.15 1.0 0.5  0.015 0.5 6.0-10.0 72.0min 14.0-17.0
Inconel 601 0.10 1.0 0.5 0.015 1.0 Bal 58.0-63.0 21.0-25.0
Inconel 625 0.10 0.50 0.5 0.015 - 5.0max 58.0 min 20.0-23.0
Inconel 718 0.08 0.35 0.35 0.015 0.30 - 50.0-55.0 17.0-21.0

Inconel 600, 601, 625, 718 steel plates/sheets/coils Mechanical Properties:

Mechanical properties Tensile, min, ksi[MPa] Yield, min, ksi[MPa] Elongation, %(min)
Inconel 600 80[550] 35[240] 30
Inconel 601 80[552] 30[205] 30
Inconel 625 100[690] 40[276] 30
Inconel 718 185[1275] 150[1034] 12
Inconel 600, 601, 625, 718 steel plates/sheets/coils Equivalent Grades:
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 600 2.4816 N06600 NCF 600 NA 13 МНЖМц 28-2,5-1,5 NC15FE11M NiCr15Fe
Inconel 601 2.4851 N06601 NCF 601 NA 49 XH60BT NC23FeA NiCr23Fe
Inconel 625 2.4856 N06625 NCF 625 NA 21 ХН75МБТЮ NC22DNB4M NiCr22Mo9Nb
Inconel 718 2.4668 N07718 NCF 718 - - - -
Duplex steel Plate supplierInconel steel Plate supplier Inconel 600 steel Plate S31803 steel CoilInconel 625 steel Coil
inconel-601-sheet.Inconel 601 Sheet Inconel 718 steel Coil Inconel 625 steel Sheet
Surface: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching.
VALUE ADDED SERVICES:
Cutting
Bending
Forging
Rolling
Heat Treatment
Fabrication
Applications industries:
Transport, storage and chemical processing
Processing equipment
High chloride and marine environments
Oil and gas exploration
Paper machines, liquor tanks, pulp and paper digesters
