Monel Bars & Rods

  • Material: Hastelloy B2, B3, X, C22, C2000, C276
  • Type: Round bar,Square bar,Hex bar,Flat bar
  • Length: 0~12M or as per your requirements
  • Tolerance: H7 H9 H10 H11

PRODUCT DESCRIPTION

Monel Bars is Nickel based alloy with high Nickel, Chromium, and Molybdenum content. Monel 400 Rods / Bars  has a wide range of mechanical properties at elevated temperatures. Monel K500 rod has provided very good yield strength as well as tensile strength. Also with this, Monel K500 Bars offer very good toughness even at the down to the cryogenic temperatures.

HT PIPE is a manufacturer, exporter, and supplier of Monel Round Bars, Monel Hollow bars, Monel Square Bars, Monel Hex Bars & Rods accoding to the material standard ASTM B164: Monel 400 bar, Monel K500 bar.

Specification For Monel Rods / Bars:
Dimensions Standard: EN, DIN, JIS, ASTM, BS, ASME, AISI
Round Bars diameter: 5-500mm
Hex Bars: 2mm~100mm
Square Bars: 4mm*4mm~100mm*100mm
Flat Bars: 1/2” to 10” in thickness range of 2mm to 150mm
Finish: Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish

Round bar supplierRound Bar Supplier hastelloy round barMonle400 Round Bar Hastelloy C276 Round BarMonel K500 Round Bar
Duplex flat steel barMonel steel Flat bar Duplex Hex steel barMonel steel Hex bar Duplex steel Square barMonel steel Square bar

Monel Rods / Bars Chemical Composition:

Grade C≤ Mn≤ Si S≤ Cu Fe≤ Ni
Monel400 0.3 2 0.5 0.024 28.0-34.0 2.5 63
K500 0.25 1.5 0.5 0.01 27.0-33.0 0.5-2 63

Monel Rods / Bars Mechanical Properties:

Mechanical properties Tensile, min, ksi[MPa] Yield, min, ksi[MPa] Elongation, %(min)
Monel 400 80[550] 35[240] 40
Monel K500 160[1100] 115[790] 20
Monel Rods / Bars Equivalent Grades:
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Monel 400 2.436 N04400 NW 4400 NA 13 МНЖМц 28-2,5-1,5 NU-30M NiCu30Fe
Monel K500 2.4375 N05500
VALUE ADDED SERVICES:
Forging
Rolling
Heat Treatment
Applications industries:
Oil and Gas Industries
Food Processing Industries
Equipment; Pipeline
Power Industries; Ship Building Industries
Paper Industries; Cement Industries; Chemical Industries ect.
Monel Rods / Bars Packing: Loose / Carrate / Wooden Pallet / Wooden Box / Plastic Cloth Wraps
