Incoloy Bars & Rods

  • Material Standard: Incoloy 800/800H/800HT/825
  • Type: Round bar,Square bar,Hex bar,Flat bar
  • Length: 0~12M or as per your requirements
  • Tolerance: H7 H9 H10 H11

PRODUCT DESCRIPTION

Incoloy alloy is a nickel-chromium alloy with high strength and superb resistance. Also, it is completely resistant to pitting, abrasion and erosion. HT PIPE is a profesional supplier and exporter of Incoloy Round Bar, we offer the wide comprehensive range of bar that varies in different specifications: Incoloy 800 / 800H / 800HT / 825 Bars.

Incoloy 800 Bars is a Nickel-Chromium Alloy having high temperature resistance,  Incoloy 800H Bars offer resistance to several corrosive atmospheres, such as crevice corrosion, pitting, stress corrosion cracking and intergranular corrosion. Our Incoloy 800HT Bars are extremely resistant to stress related corrosion cracking, along with being resistant to localized attack such as pitting and crevice corrosion.

HT PIPE is a manufacturer, exporter, and supplier of Incoloy Round Bars, Incoloy Hollow bars, Incoloy Square Bars, Incoloy Hex Bars & Rods accoding to the material standard ASTM B425, ASTM B408, ASTM B649: Incoloy 800 bar, Incoloy 800H bar, Incoloy 800HT bar, Incoloy 825 bar.
Specification For Incoloy Rods / Bars:
Dimensions Standard: EN, DIN, JIS, ASTM, BS, ASME, AISI
Round Bars diameter: 5-500mm
Hex Bars: 2mm~100mm
Square Bars: 4mm*4mm~100mm*100mm
Flat Bars: 1/2” to 10” in thickness range of 2mm to 150mm
Finish: Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish

Incoloy Round Bar Supplier Incoloy 825 Bar Incoloy 800/800H/800HT Bar
Incoloy Flat BarIncoloy Flat Bar Incoloy Hex BarIncoloy Hex Bar Incoloy Square BarIncoloy Square Bar

Incoloy 800/800H/800HT/825 Rods & Bars Chemical Composition:

Grade C≤ Mn≤ Si≤ S≤ Cu≤ Fe(min) Ni Cr Al Ti
800 0.1 1.5 1.0  0.015 0.75 39.5 30.0-35.0 19.0-23.0 0.15-0.60 0.15-0.60
800H 0.05-0.10 1.5 1.0  0.015 0.75 39.5 30.0-35.0 19.0-23.0 0.15-0.60 0.15-0.60
800HT 0.06-0.10 1.5 1.0  0.015 0.75 39.5 30.0-35.0 19.0-23.0 0.85-1.20 0.25-0.60
825 0.05 1.0 0.5 0.03 0.5-3.0 22.0 38.0-46.0 19.5-23.5 0.2max 0.6-1.2

Incoloy 800/800H/800HT/825 Rods & Bars Mechanical properties:
Mechanical properties Tensile, min, ksi[MPa] Yield, min, ksi[MPa] Elongation, %(min)
Incoloy 800 75[517] 30[207] 30
Incoloy 800H 65[448] 25[172] 30
Incoloy 800HT 65[448] 25[172] 30
Incoloy 825 85[586] 35[241] 30
Incoloy 800/800H/800HT/825 Rods & Bars Equivalent Grades:
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 800 1.4876 N08800 NCF 800 NA 15 ЭИ670 Z8NC32-21 X10NiCrAlTi32-20 XH32T
Incoloy 800H 1.4958 / 1.4876 N08810 NCF 800H NA 15(H) ЭИ670 Z8NC33-21 X5NiCrAlTi31-20 XH32T
Incoloy 800HT 1.4959 / 1.4876 N08811 NCF 800HT NA 15(HT) ЭИ670 X8NiCrAlTi32-21 XH32T
Incoloy 825 2.4858 N08825 NCF 825 NA 16 ЭП703 NFE30C20DUM NiCr21Mo XH38BT
VALUE ADDED SERVICES:
Forging
Rolling
Heat Treatment
Applications industries:
Oil and Gas Industries
Food Processing Industries
Equipment; Pipeline
Power Industries; Ship Building Industries
Paper Industries; Cement Industries; Chemical Industries ect.
Incoloy Rods / Bars Packing:Loose / Carrate / Wooden Pallet / Wooden Box / Plastic Cloth Wraps
