Incoloy steel plate sheet Coil

Incoloy alloy plates is a nickel-chromium alloy with high strength and superb resistance. Also, it is completely resistant to pitting, abrasion and erosion. HT PIPE is a manufacturer, exporter, and supplier of Incoloy  plates sheets and coils as the material grade ASTM B409 Incoloy 800, Incoloy 800H, Incoloy 800HT, ASTM B424 Incoloy 825.

Specification For Incoloy 800/800H/800HT/825 steel plates/sheets/coils:
Thickness: 0.1mm to 12 mm Thk
Sheet/Plate Size: 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Coil Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc.
Coil Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc.

Grade	C≤	Mn≤	Si≤	S≤	Cu≤	Fe(min)	Ni	Cr	Al	Ti
800	0.1	1.5	1.0	0.015	0.75	39.5	30.0-35.0	19.0-23.0	0.15-0.60	0.15-0.60
800H	0.05-0.10	1.5	1.0	0.015	0.75	39.5	30.0-35.0	19.0-23.0	0.15-0.60	0.15-0.60
800HT	0.06-0.10	1.5	1.0	0.015	0.75	39.5	30.0-35.0	19.0-23.0	0.85-1.20	0.25-0.60
825	0.05	1.0	0.5	0.03	0.5-3.0	22.0	38.0-46.0	19.5-23.5	0.2max	0.6-1.2

Incoloy 800/800H/800HT/825 steel plates/sheets/coils Mechanical Properties:

Mechanical properties	Tensile, min, ksi[MPa]	Yield, min, ksi[MPa]	Elongation, %(min)
Incoloy 800	75[517]	30[207]	30
Incoloy 800H	65[448]	25[172]	30
Incoloy 800HT	65[448]	25[172]	30
Incoloy 825	85[586]	35[241]	30

Incoloy 800/800H/800HT/825 steel plates/sheets/coils Equivalent Grades:

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN	OR
Incoloy 800	1.4876	N08800	NCF 800	NA 15	ЭИ670	Z8NC32-21	X10NiCrAlTi32-20	XH32T
Incoloy 800H	1.4958 / 1.4876	N08810	NCF 800H	NA 15(H)	ЭИ670	Z8NC33-21	X5NiCrAlTi31-20	XH32T
Incoloy 800HT	1.4959 / 1.4876	N08811	NCF 800HT	NA 15(HT)	ЭИ670	–	X8NiCrAlTi32-21	XH32T
Incoloy 825	2.4858	N08825	NCF 825	NA 16	ЭП703	NFE30C20DUM	NiCr21Mo	XH38BT

Incoloy steel Plate supplier	Incoloy 800 steel Plate	Incoloy 800H steel Coil
Incoloy 800H Sheet	Incoloy 800 steel Coil	Incoloy 825 steel Sheet

Surface: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching.
VALUE ADDED SERVICES:

Cutting

Bending

Forging

Rolling

Heat Treatment

Fabrication
Applications industries:

Transport, storage and chemical processing

Processing equipment

High chloride and marine environments

Oil and gas exploration

Paper machines, liquor tanks, pulp and paper digesters
