ASME SB-127/ASTMB127 is the Standard Specification for Nickel-Copper Alloy (UNS N04400) Plate, Sheet, and Strip. HT PIPE is a manufacturer, exporter, and supplier of Monel steel plates, the Manufacturer of Monel 400 plates, Monel 400 sheets, Monel 400 coils, Monel K500 plates sheets coils Material stockist in China.
Specification For Monel 400, K500 steel plates/sheets/coils:
Thickness: 0.1mm to 12 mm Thk
Sheet/Plate Size: 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Coil Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc.
Coil Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc.
Monel 400, K500 steel plates/sheets/coils Chemical Composition:
| Grade |
C≤ |
Mn≤ |
Si |
S≤ |
Cu |
Fe≤ |
Ni |
| Monel400 |
0.3 |
2 |
0.5 |
0.024 |
28.0-34.0 |
2.5 |
63 |
| K500 |
0.25 |
1.5 |
0.5 |
0.01 |
27.0-33.0 |
0.5-2 |
63 |
Monel 400, K500 steel plates/sheets/coils Mechanical Properties:
| Mechanical properties |
Tensile, min, ksi[MPa] |
Yield, min, ksi[MPa] |
Elongation, %(min) |
| Monel 400 |
80[550] |
35[240] |
40 |
| Monel K500 |
160[1100] |
115[790] |
20 |
Monel 400, K500 steel plates/sheets/coils Equivalent Grades:
| STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
BS |
GOST |
AFNOR |
EN |
| Monel 400 |
2.436 |
N04400 |
NW 4400 |
NA 13 |
МНЖМц 28-2,5-1,5 |
NU-30M |
NiCu30Fe |
| Monel K500 |
2.4375 |
N05500 |
– |
– |
– |
– |
– |
 Monel steel Plate supplier |
 Monel 400 sheet supplier |
 Monel 400 steel Coil |
 Monel 400 sheet |
 Monel steel Coil |
 Monel K500 Sheet |
Surface: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching.
VALUE ADDED SERVICES:
Cutting
Bending
Forging
Rolling
Heat Treatment
Fabrication
Applications industries:
Transport, storage and chemical processing
Processing equipment
High chloride and marine environments
Oil and gas exploration
Paper machines, liquor tanks, pulp and paper digesters
