904L Stainless steel consists of Chromium, Nickel, Molybdenum and Copper contents, these elements make 904L stainless steel excellent properties to resist corrosion in dilute sulfuric acid, because of the addition of Copper, 904L commonly is used in high pressure and corrosion environment where 316L and 317L perform poorly.
HT PIPE supplys the high quality
904L stainless steel pipes, equivalent grades are DIN 1.4539 and UNS N08904. All pipes are subjected to extensive tests like a hydraulic test, to make sure that there is no leakage and each pipe passes through a prescribed quality control process in order to make sure the best quality.
904L Stainless Steel Pipe(Tube) Standards
ASTM A 312 – seamless, welded, and heavily cold worked austenitic stainless steel pipes
ASTM A 213 – seamless ferritic and austenitic alloy-steel boiler, super heater, and heat-exchanger tubes
ASTM A 269 – seamless and welded austenitic stainless steel tubing for general service
ASTM B 677 – uns n08904, uns n08925, and uns n08926 seamless pipe and tube
Seamless tube is extruded and drawn from a billet while welded tube is produced from a strip that is roll formed and welded to produce a tube.
Welded tube is considerably less expensive than seamless tube and is readily available in long continuous lengths.
Electric Resistance Welded (ERW) pipe is manufactured by cold forming a flat steel strip into a rounded tube and passing it through a series of forming rollers to obtain a longitudinal seam.
The two edges are then simultaneously heated with a high frequency current and squeezed together to form a bond.
1. 904L Stainless Steel Seamless and Welded Heat-Exchanger and Condenser Pipe and Tubes Specifcation
| Standard |
ASTM, DIN, GB, AISI, JIS, ISO, etc other International Standards |
| Dimensions |
ASTM, ASME and API |
| Specifications |
ASTM A312, A213, A269, B677 |
| ERW Pipes & Tubes Size |
1/2″ NB – 24″ NB |
| EFW Pipes & Tubes Size |
6″ NB – 100″ NB |
| Pipes & Tubes Size |
1/2″ NB – 16″ NB |
| Length |
Single Random, Double Random & Required Length or As per Customer Requirement |
| Schedule |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Types |
SMLS / ERW / EFW / Welded / Fabricated / LSAW Pipes |
| Form |
Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, "U" Shape, Pan Cake Coils, Hydraulic Tubes |
| End |
Plain End, Beveled End, Treaded |
| Application |
Food & Beverage Industry, Construction Industry, Nuclear, Thermal & Power Plants, Petrochemical, Boilers, Cement Industry, Geothermal Plants, Heat Exchangers, Instrumentation Jobs, Mechanical Jobs, Oil and Gas Equipments and Piping Works |
| Package |
Plastic caps on botd ends, Steel bundle, Woven bag or acc. to customers' request |
2. About Stainless Steel 904L Pipe Tube, 904L SS Pipes,Tubing Equivalent
| STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
AFNOR |
BS |
KS |
EN |
| SS 904L |
1.4539 |
N08904 |
SUS 904L |
Z2 NCDU 25-20 |
904S13 |
STS 317J5L |
X1NiCrMoCu25-20-5 |
904L SS Pipes,Tubes Chemical Properties
| Grade |
|
C |
Mn |
Si |
P |
S |
Cr |
MO |
Ni |
CU |
| 904L |
Min |
– |
– |
– |
– |
– |
19.0 |
4.00 |
23.00 |
1.00 |
| max |
0.20 |
2.00 |
1.00 |
0.045 |
0.035 |
23.0 |
5.00 |
28.00 |
2.00 |
SS 904L Mechanical Properties
| Density |
8.0 g/cm3 |
| Melting Point |
1454 °C (2650 °F) |
| Tensile Strength |
Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) |
Psi – 30000 , MPa – 205 |
| Elongation |
35 % |
3. Other Types Of TP SS 904L Pipes & Tubes
| Stainless Steel 904L Welded Pipe |
904L SS Welded Pipe
SS 904L ERW Pipe
SS 904L EFW Pipe
Stainless Steel 904L ERW Pipe
Stainless Steel 904L EFW Pipe
904L Stainless Steel Welded Pipe
UNS N08904 Welded Pipe
WERKSTOFF NR. 1.4539 Welded Pipe
ASTM B677 TP 904L Stainless Steel Welded Pipes |
| Stainless Steel 904L Round Pipe |
SS 904L Round Pipe
904L Stainless Steel Round Pipe
UNS N08904 Round Pipe
SS UNS N08904 Round Pipe
ASTM B677 TP 904L Stainless Steel Round Pipes |
| Stainless Steel 904L Square Pipe |
SS 904L Square Pipe
904L Stainless Steel Square Pipe
UNS N08904 Square Pipe
WERKSTOFF NR. 1.4539 Square Pipe
ASTM B677 TP 904L Stainless Steel Square Pipes |
| Stainless Steel 904L Rectangular Pipe |
SS 904L Rectangular Pipe
904L Stainless Steel Rectangular Pipe
UNS N08904 Rectangular Pipe
WERKSTOFF NR. 1.4539 Rectangular Pipe
ASTM B673 TP 904L Stainless Steel Rectangular Pipes |
| Custom Stainless Steel 904L Pipe |
SS 904L Custom Pipe
904L Stainless Steel Custom Pipe
UNS N08904 Custom Pipe
WERKSTOFF NR. 1.4539 Custom Pipe
ASTM B673 TP 904L Stainless Steel Custom Pipes |
| Stainless Steel 904L Polished Pipe |
SS 904L Polished Pipe
904L Stainless Steel Polished Pipe
UNS N08904 Polished Pipe
WERKSTOFF NR. 1.4539 Polished Pipe
ASTM B677 TP 904L Stainless Steel Polished Pipes |
| Stainless Steel 904L Decorative Pipe |
SS 904L Decorative Pipe
904L Stainless Steel Decorative Pipe
UNS N08904 Decorative Pipe
WERKSTOFF NR. 1.4539 Decorative Pipe
ASTM B673 TP 904L Stainless Steel Decorative Pipes |
